GTWY2-16 HIGH QUALITY 14M MANUAL HYDRAULIC DOUBLE MASTS VERTICAL LIFT AERIAL WORKING PLATFORMS

Model: GTWY2-16

Loading Capacity: 150kg

Occupants: 2

Max. Working Height: 18m

Max. Platform Height: 16m

Weight:

AC: 996kg

DC: 1046kg

Available commodity

Certificate of Origin (CO) issued by the manufacturer accompanying the product

Giá: 0932182327

Mã sản phẩm: GTWY2-16

Model: GTWY2-16

Double Masts Vertical lift
Model	GTWY2-8	GTWY2-10	GTWY2-12	GTWY2-14	GTWY2-16
Platform
Max. Working Height	10m	12.4m	14m	16m	18m
Max. Platform Height	8m	10.4m	12m	14m	16m
Loading Capacity	250kg	250kg	200kg	200kg	150kg
Occupants	2	2	2	2	1
Platform Dimension	1.45m x 0.7m	1.45m x 0.7m	1.45m x 0.7m	1.8m x 0.7m	1.8m x 0.7m
Overall Dimension
Overall Height	1.99m	1.99m	1.99m	2.68m	2.68m
Overall Width	0.81m	0.81m	0.81m	0.81m	0.81m
Overall Length	1.45m	1.45m	1.45m	1.88m	1.88m
Outrigger coverage	2.45m x 1.75m	2.45m x 2.1m	2.45m x 2.1m	2.7m x2.8m	2.7m x2.8m
Weight
AC	645kg	715kg	750kg	892kg	996kg
DC	695kg	765kg	800kg	942kg	1046kg
Power
AC	380V/220V/110V	380V/220V/110V	380V/220V/110V	380V/220V/110V	380V/220V/110V
AC Motor	1.5KW	1.5KW	1.5KW	1.5KW	1.5KW
DC	2x12V	2x12V	2x12V	2x12V	2x12V
DC motor	2.2KW	2.2KW	2.2KW	2.2KW	2.2KW
Charger	12V/15A	12V/15A	12V/15A	12V/15A	12V/15A

TỪ KHÓA TÌM KIẾM: XE NÂNG NGƯỜI LÀM VIỆC 4M, XE NÂNG NGƯỜI LÀM VIỆC 3M, XE NÂNG NGƯỜI LÀM VIỆC 3.6M, XE NÂNG NGƯỜI LÀM VIỆC 4.8M, XE NÂNG NGƯỜI LÀM VIỆC 6.5, XE NÂNG NGƯỜI LÀM VIỆC 7.7M, XE NÂNG NGƯỜI LÀM VIỆC 9M, MÁY NÂNG 12M, MÁY NÂNG 14M, XE NÂNG NGƯỜI LÀM VIỆC 16M.

Double Masts Vertical lift
Model	GTWY2-8	GTWY2-10	GTWY2-12	GTWY2-14	GTWY2-16
Platform
Max. Working Height	10m	12.4m	14m	16m	18m
Max. Platform Height	8m	10.4m	12m	14m	16m
Loading Capacity	250kg	250kg	200kg	200kg	150kg
Occupants	2	2	2	2	1
Platform Dimension	1.45m x 0.7m	1.45m x 0.7m	1.45m x 0.7m	1.8m x 0.7m	1.8m x 0.7m
Overall Dimension
Overall Height	1.99m	1.99m	1.99m	2.68m	2.68m
Overall Width	0.81m	0.81m	0.81m	0.81m	0.81m
Overall Length	1.45m	1.45m	1.45m	1.88m	1.88m
Outrigger coverage	2.45m x 1.75m	2.45m x 2.1m	2.45m x 2.1m	2.7m x2.8m	2.7m x2.8m
Weight
AC	645kg	715kg	750kg	892kg	996kg
DC	695kg	765kg	800kg	942kg	1046kg
Power
AC	380V/220V/110V	380V/220V/110V	380V/220V/110V	380V/220V/110V	380V/220V/110V
AC Motor	1.5KW	1.5KW	1.5KW	1.5KW	1.5KW
DC	2x12V	2x12V	2x12V	2x12V	2x12V
DC motor	2.2KW	2.2KW	2.2KW	2.2KW	2.2KW
Charger	12V/15A	12V/15A	12V/15A	12V/15A	12V/15A

Double Masts Vertical lift
Model	GTWY2-8	GTWY2-10	GTWY2-12	GTWY2-14	GTWY2-16
Platform
Max. Working Height	10m	12.4m	14m	16m	18m
Max. Platform Height	8m	10.4m	12m	14m	16m
Loading Capacity	250kg	250kg	200kg	200kg	150kg
Occupants	2	2	2	2	1
Platform Dimension	1.45m x 0.7m	1.45m x 0.7m	1.45m x 0.7m	1.8m x 0.7m	1.8m x 0.7m
Overall Dimension
Overall Height	1.99m	1.99m	1.99m	2.68m	2.68m
Overall Width	0.81m	0.81m	0.81m	0.81m	0.81m
Overall Length	1.45m	1.45m	1.45m	1.88m	1.88m
Outrigger coverage	2.45m x 1.75m	2.45m x 2.1m	2.45m x 2.1m	2.7m x2.8m	2.7m x2.8m
Weight
AC	645kg	715kg	750kg	892kg	996kg
DC	695kg	765kg	800kg	942kg	1046kg
Power
AC	380V/220V/110V	380V/220V/110V	380V/220V/110V	380V/220V/110V	380V/220V/110V
AC Motor	1.5KW	1.5KW	1.5KW	1.5KW	1.5KW
DC	2x12V	2x12V	2x12V	2x12V	2x12V
DC motor	2.2KW	2.2KW	2.2KW	2.2KW	2.2KW
Charger	12V/15A	12V/15A	12V/15A	12V/15A	12V/15A
