Output Pressure: 700bar / 70Mpa
Oil Delivery at Low Pressure: 7.5L/min
Oil Delivery at High Pressure: 1.2L/min
Tank Capacity: 10L
Rated Engine Speed: 3600 rpm
Dimension: 650×370×500mm
Net Weight (Hydraulic Oil Included): 53kgs
Technical Data:
Output Pressure |
700bar / 70Mpa |
Oil Delivery at Low Pressure |
7.5L/min |
Oil Delivery at High Pressure |
1.2L/min |
Tank Capacity |
10L |
Rated Engine Speed |
3600 rpm |
Dimension |
650×370×500mm |
Net Weight (Hydraulic Oil Included) |
53kgs |
Features:
1. Large oil capacity, suitable for large capacity crimping tools and long time
operation without engine overheating.
2. High and low double-speed automatic switch, well fit for 60T 100T 200T 300T
crimping tools.
3. Rated output pressure 70Mpa, maximum up to 90Mpa.
4. Retract pressure protection system &overflow protection valve,safe and reliable.
5. Simple structure, easy operation, light weight.
6.Low noise, environment friendly.
7. Equipped with pressure gauge for easy output confirmation.
