M42 Foundation Bolt Tensioner

Wind Mill Bolt Tensioners

M42 Foundation Bolt Tensioner
These 1500 bar working pressure tensioners are specially developed from our Compact series to meet auto retract an ease of operation requirement of wind mill application.

Giá: 0932182327

Mã sản phẩm: Foundation Bolt Tensioner

Model: FBT-42-M42

Compact Design: The tensioners are designed with smaller dia for ease of tool fitment.
Higher Working Pressure: 1500 bar working pressure to generate higher load with smaller hydraulic area of tensioner.
Geared Nut Drive: Geared Nut Driver to move the nut faster and with ease using standard Square Drive Wrench.
Longer Stroke: Tool is available with standard and long stroke as per application.
Alloy Steel Construction: All parts are made from High Strength Alloy Steel better strength and compact. design.
Customised Adaptor Kits: CAT series tensioners are available with both tomised adaptor kit.

Optional Auto Spring Return: Standard tensioners are available with optional auto spring retraction for fast and easy retraction of piston.

Model No.	Bolt size		Max load	Max Dia	Strock
Model No.	Metric	Imperial	kN	mm	Standard (mm)	Long (mm)
FBT-27-M24	M24	1""	271	74	15	25
FBT-27-M27	M27	1-1/8"	271	74	15	25
FBT-33-M30	M30	1-1/4"	369	86	15	25
FBT-33-M33	M33	1-1/4"	369	86	15	25
FBT-36-M33	M33	1-3/8"	767	118	15	25
FBT-36-M36	M36	1-3/8"	767	118	15	25
FBT-42-M39	M39	1-1/2"	820	123	15	25
FBT-42-M42	M42	1-5/8"	820	123	15	25
