LP Adapters NPT male to MP female, Stainless Steel

LP Adapters NPT male to MP female, Stainless Steel

LP Adapters, NPT to MP, Stainless Steel

LP (Max 15k PSI)Adapters

Industry standard adapters for 1/8" to 1" NPT to MP tubes sizes 1/4", 3/8", 9/16" and 1". Compact designs, made from NACE certified AISI 316L / EN1.4404 stainless steel for maximum life and safety weep holes on all the connection ports.

Giá: 0932182327

Mã sản phẩm: NPT male to MP female

Model: 199501963, 199501964, 199501965, 199501966, 199501967, 199501968, 199501969

LP Adapters, NPT to MP, Stainless Steel (Max 15k PSI)
Part No.	Category	Rec. torque (Nm)	Connection 1	Connection 2	Max working pressure
199501963	NPT male to MP female	conn.1: 29 conn.2: 41 Nm	1/4" NPT	3/8" MP	103.4 MPa
199501964	NPT male to MP female	conn.1: 34 conn.2: 41 Nm	3/8" NPT	3/8" MP	103.4 MPa
199501965	NPT male to MP female	conn.1: 61 conn.2: 41 Nm	1/2" NPT	3/8" MP	103.4 MPa
199501966	NPT male to MP female	conn.1: 29 conn.2: 75 Nm	1/4" NPT	9/16" MP	103.4 MPa
199501967	NPT male to MP female	conn.1: 34 conn.2: 75 Nm	3/8" NPT	9/16" MP	103.4 MPa
199501968	NPT male to MP female	conn.1: 61 conn.2: 75 Nm	1/2" NPT	9/16" MP	103.4 MPa
199501969	NPT male to MP female	conn.1: 163 conn.2: 75 Nm	1" NPT	9/16" MP	103.4 MPa
